Freedom WCFC JATO Foilboard

Size: 3’10”

Details:

Whether they were representing down at the Dog Patch or logging sky miles at outer reef breaks, The Hurley Brothers were known to fly boards that were incomprehensibly small. Designed to allow for a maximum connection to the foil, the J.A.T.O. short for Jet Assisted Take Off, is a surf inspired tow board design that was tried and tested by the Original Gangsters of Foil.

Features:

• Flat Deck with Reverse Tail Rocker
• Sharp Chined Rails
• Flat Bottom
• Step Tail
• Narrow Outline
• Proprietary FFB 10.75″ Mounting Tracks
• Pressure Relief Air Vent
• Foot Strap Inserts

Specs:

Length (ft/in)	Width (in)	Thickness (in)	Volume (L)
3’10”	18”	1.75”	16.25L

FFB BOARD CONSTRUCTION

There have been no corners cut when it come to the construction of all Freedom Foil Boards. With the highest quality materials and manufacturing process, our boards are some of the lightest on the market while being reliable ride after ride.

1. E Glass – Protective layer over paint and carbon
2. Carbon Double Bias – High Grade Woven Carbon with extra fibers running in the longitudinal axis
3. S Glass – Impact resistant layer of fiberglass to distribute loading from heels, hard landings, ect.
4. EPS – Lightweight stringer less foam core
5. High Density Foam Block – High Density Foam block to reinforce and keep foil tracks secure and in place
6. Carbon Uni Directional – Uni directional strip of carbon to increase stiffness and response as well as reinforce the foil track
7. Carbon Double Bias
8. E Glass
